Sandwiched product consisting of two 12.5 mm thick plasterboard panels and a IsolFIBTEC FLC panel (80 mm thermo-bonded fibre of recycled polyester).



Isolmant Setto Acustico Fibra CG is a vertical element that completes mobile partitions or plasterboard partitions and is positioned in the air plenum between the wall and the extrados of the lower floor (in the case of raised floors) or between the wall and the intrados of the upper floor (in the case of false ceilings) in order to reduce the insulation losses due to the formation of acoustic bridges (losses that can be estimated at around 10 dB) at the upper or lower vertical joints of the aforementioned construction elements. When used with raised floors, the septum can be laid without fixing to ensure easy removal for maintenance. If used above the false ceiling, mechanical fixing to the intrados of the ceiling is recommended using brackets or metal profiles.







Immagine 1

Advantages

• It can be used in both renovation and new construction.
• High acoustic insulation against airborne noise.
• Thermal insulation.
• Low thermal conductivity.
• Inalterable in time.
• Unlimited duration.
• Easy installation.
• Variable height, on request, to adapt to all site requirements.

Isolmant GreenPlanet

• Volatile Organic Compounds free (VOC A+)
• Environmentally friendly and recyclable.
• Environmentally friendly production.
• This product contributes to achieve credits for the environmental certification of a building according to LEED or ITACA standards.



This product complies with the requirements defined by Italian CAM Edilizia for acoustic and thermal insulation materials regarding the percentage of recycled material and the absence of hazardous substances.

Item specifications

Sandwiched Acoustic laminated product made of two 12.5 mm thick plasterboard panels and a IsolFIBTEC FLC panel (80 mm thermo-bonded fibre of recycled polyester). Length 120 cm, height on request up to 1 metre, soundproofing power Rw = 48 dB and thermal resistance of Rt = 2.17 m2 K/W (type Isolmant Setto Acustico CG).
